FRAME
Aluminium Ladies Specific Frame, Custom Double Butted Hydro-formed 6061 Frame, Post-mount Disc Brake Mounts. Supports 27.5" Wheelsize, including Internal Routed Cables and Dropper Post Compatible.
✨ New Arrivals Just Dropped!Explore
Splash Comp Mountain Bike
HEADSET
Steel Semi-Integrated, ZS44/28.6 ZS56/40
FRAME AXLE SPACING
135x9mm
AXLE SPECIFICATION
QR
HANGER TYPE
HANGER 22
FORK
SR Suntour XCM32 Coil, 27,5"x2,3", 100mm Travel
FORK TRAVEL
100mm
WHEELSET
Surface Custom
HUBS
F: Surface, 100x9mm QR, 6 Bolt, 32H
R: Surface, 135x9mm QR, 6 Bolt, 32H
RIMS
F: Surface 27.5" Symmetrical Alloy, Tubeless Ready
R: Surface 27.5" Symmetrical Alloy, Tubeless Ready
TYRES
CST C1820 2.35", Wire bead
MAX TYRE SIZE
2.4"
CRANKSET
Surface alloy 32T
MAX CHAINRING SIZE
36T
BOTTOM BRACKET & TYPE
BSA 73mm
SHIFTER(S)
MICROshift Xpress, 1 x 9spd
REAR DERAILLEUR
MICROshift Advent with clutch, 9spd
CASSETTE
MICROshift 11-46T, 9spd
CHAIN
KMC 9spd
BRAKES
Tektro MD-M275 Hydraulic Disc
ROTORS
F: Tektro 180mm
R: Tektro 160mm
GRIPS
Surface, Push-On
HANDLEBAR
Surface, Alloy, 31.8mm Dia. 9° backsweep, 5° rise, 680mm width
STEM
Surface, Alloy 31.8mm, 10° rise
SADDLE
Surface, Ergo, Steel Rails
SEAT POST
Surface, Alloy 30.9mm, micro adjust
SEATPOST CLAMP
Surface, Alloy
PEDALS
One-Piece Alloy
BIKE WEIGHT
14.02 kg (Including pedals)
RIDER WEIGHT LIMIT
120kg - combined weight of bike and rider (including all kit).
Select Size
From $1,695.00
Splash Comp Mountain Bike—
$1,695.00
Description
FRAME
Aluminium Ladies Specific Frame, Custom Double Butted Hydro-formed 6061 Frame, Post-mount Disc Brake Mounts. Supports 27.5" Wheelsize, including Internal Routed Cables and Dropper Post Compatible.
HEADSET
Steel Semi-Integrated, ZS44/28.6 ZS56/40
FRAME AXLE SPACING
135x9mm
AXLE SPECIFICATION
QR
HANGER TYPE
HANGER 22
FORK
SR Suntour XCM32 Coil, 27,5"x2,3", 100mm Travel
FORK TRAVEL
100mm
WHEELSET
Surface Custom
HUBS
F: Surface, 100x9mm QR, 6 Bolt, 32H
R: Surface, 135x9mm QR, 6 Bolt, 32H
RIMS
F: Surface 27.5" Symmetrical Alloy, Tubeless Ready
R: Surface 27.5" Symmetrical Alloy, Tubeless Ready
TYRES
CST C1820 2.35", Wire bead
MAX TYRE SIZE
2.4"
CRANKSET
Surface alloy 32T
MAX CHAINRING SIZE
36T
BOTTOM BRACKET & TYPE
BSA 73mm
SHIFTER(S)
MICROshift Xpress, 1 x 9spd
REAR DERAILLEUR
MICROshift Advent with clutch, 9spd
CASSETTE
MICROshift 11-46T, 9spd
CHAIN
KMC 9spd
BRAKES
Tektro MD-M275 Hydraulic Disc
ROTORS
F: Tektro 180mm
R: Tektro 160mm
GRIPS
Surface, Push-On
HANDLEBAR
Surface, Alloy, 31.8mm Dia. 9° backsweep, 5° rise, 680mm width
STEM
Surface, Alloy 31.8mm, 10° rise
SADDLE
Surface, Ergo, Steel Rails
SEAT POST
Surface, Alloy 30.9mm, micro adjust
SEATPOST CLAMP
Surface, Alloy
PEDALS
One-Piece Alloy
BIKE WEIGHT
14.02 kg (Including pedals)
RIDER WEIGHT LIMIT
120kg - combined weight of bike and rider (including all kit).
